Application
QS5 cam starter is mainly used to start forward or backward and stop directly three-phase asynchronous electric motor with AC 50Hz, voltage up to 500V and capacity up to 7.5KW. It can also be used for changeover from one kind of circuit to the other.
Specification
Model Mark Rated
current
(A)
Motor contro capacity
(HP)
Mechanical life
(times)
Frequency of operation
(per hr)
Applications Position
of lever
QS5-15A Ⅰ-○ 15 5.5 250000 200 ON-OFF
switching
0-60
QS5-30A 30 10
QS5-15A Ⅰ-○-Ⅰ 15 5.5 Forward
& reverse
60-0-60
QS5-30A 30 10
QS5-15P/3 Ⅰ-○-Ⅱ 15 5.5 for 3 pole
two circuit
60-0-60
QS5-30P/3 30 10
QS5-63A Ⅰ-○ 63 22 200000 180 ON-OFF
switching
0-60
QS5-100A 100 30
QS5-63N Ⅰ-○-Ⅰ 63 22 Forward
& reverse
60-0-60
QS5-100N 100 30
QS5-63P/4 Ⅰ-○-Ⅱ 63 22 for 3 pole
two circuit
60-0-60
QS5-100P/4 100 30
